Tutorial 2: Teleportation

Suppose Alice possesses a pure state \(\psi = U \triangleleft \pi_0\) of a qubit (equivalently, \(|\psi\rangle = U|\psi_0\rangle\)) where \(\pi_0(\cdot) = \langle 0| \cdot |0\rangle\), and \(U\) is a unitary operator. (We'll discuss the specific form unitaries take, and generalizations to qudits, in the exercises below.) In yaw, we can define a function which applies an operator to \(\pi_0\):

yaw> $alg = qubit()
yaw> pi0 = char(Z, 0)
yaw> def alice(U):
...    return U << pi0

For instance, the \(\pi_+(\cdot) = \langle +|\cdot|+\rangle\) state is simply \(H \triangleleft \pi_0\) (the analogue of \(H|0\rangle = |+\rangle\)).

The next stage is to prepare a Bell pair \(\phi\). We covered this at the end of the the introductory tutorial, but we'll review it briefly.:

yaw> H = (X + Z)/sqrt(2)
yaw> CNOT = ctrl(Z, [I, X])
yaw> phi_circ = CNOT*(H @ I)
yaw> phi  = phi_circ << pi0 @ pi0

The combined initial state is just aliceSends(U) tensored with phi:

yaw> def initial_state(U):
...    return alice(U) @ phi

Unfortunately, this has a nested tensor structure which yaw currently has trouble with. This needs to be manually "flattened" by defining

yaw> def initial_state(U):
...      return (U @ phi_circ) << pi0 @ pi0 @ pi0

This is exactly the same thing, but without parantheses separating the tensor products!

Recall from the previous tutorial that for two qubits, we have a set of entangled Bell states \[ \phi_{ab} = \text{CNOT}(H\otimes I) \triangleleft (\pi_a \otimes \pi_b). \] In yaw:

yaw> def phi(a, b):
...      init = char(Z, a) @ char(Z, b)
...      return phi_circ << init

The projectors \(\Pi_a = |a\rangle\langle a|\) are dual to the states \(\pi_a(\cdot) = \langle a |\cdot|a\rangle\), in the sense that \[ \pi_a(\Pi_b) = \delta_{ab}. \] Similarly, the dual projectors to the Bell states \(\phi_{ab}\) are the Bell projectors \[ \Phi_{ab} = [\text{CNOT}(H\otimes I)]^\dagger \triangleright (\Pi_a \otimes \Pi_b). \] We can define them by ⊕ The .e after the projector forces it to expand algebraically; this is currently needed to prevent errors downstream, but will be fixed in future versions.

yaw> def Phi(a, b):
...      init = proj(Z, a).e @ proj(Z, b).e
...      return phi_circ.d >> init

We can check these are dual, e.g.

yaw> Phi(1, 0) | phi(1, 0)
1
yaw> Phi(1, 0) | phi(0, 0)
0.0
yaw> Phi(1, 0) | phi(0, 1)
0.0
yaw> Phi(1, 0) | phi(1, 1)
0.0

Now that we've defined the projectors, we should measure with respect to them. That necessitates that we introduce measurement!

A projector-valued measurement (PVM) or projective measurement is a set of projectors \(\Pi_i\) that are orthogonal and "resolve the identity": \[ \Pi_i \Pi_j = \delta_{ij}\Pi_i, \quad \sum_i \Pi_i = I. \] If we measure in state \(\pi\), then (according to Born's rule) with probability \[ p_i = \pi(\Pi_i), \] we observe \(i\), and (according to the Lüders rule) the post-measurement state is \[ \pi'_i = \frac{1}{p_i} (\Pi_i \triangleleft \pi). \] This is stochastic. We can implement it in yaw using the stMeasure method, which returns the post-measurement state \(\pi'_i\) and index \(i\):

yaw> PVM = [Pi1, Pi2, ...]
yaw> measure = stMeasure(PVM, state)
yaw> measure()
(measured_state, index)

The method opMeasure does something similar, but instead of returning the state \(\pi'_i\), returns the operator \(\Pi_i\). It works for channels more generally, but we leave a full discussion to another tutorial!

For Alice's Bell measurement, we already have initial_state(U), so we just need to define the Bell PVM. Since it does nothing to Bob's qubit, we can write

yaw> bell_PVM = [Phi(0,0)@I, Phi(0,1)@I, Phi(1,0)@I, Phi(1,1)@I]

We order them this way so that, from index \(i\) observed, we can easily read off the bits by simply converted into binary. The measurement is then

yaw> bell_measure = stMeasure(bell_PVM, initial_state(U))
yaw> measured, index = bell_measure()

Now, according to the usual lore, Bob has a masked version of Alice's state. Once she tells him index, he can unmask it!

In general, Bob will apply a correction operator based on the index \(ab\) in binary:

yaw> def correction(a, b):
...      return X**a * Z**b

Running this experiment with \(U = H\), I get

yaw> index
1

This correponds to \(ab = 01\) in binary. This means Bob applies \(Z\) to recover the state, i.e. the total state is

yaw> corrected = (I @ I @ correction(0, 1)) << measured

We can test that this has the correct properties. For instance, for \(U = H\), the transported state \(\pi_+\) is characterized by its expectations: \[ \pi_+(X)= \langle +|X|+\rangle = 1, \quad \pi_+(Y) = \pi_+(Z) = 0. \] We can check:

yaw> I @ I @X | corrected
1
yaw> I @ I @ Z | corrected
0.0
yaw> I @ I @ X*Z | corrected
0.0

So we have successfully teleported! Feel free to repeat the experiment with your own unitary \(U\) and see what happens. If you need some inspiration picking a unitary, check out the first exercise below!

Let's briefly summarize the code, in compiled form:

$alg = <X, Z | herm, unit, anti>

# Basic definitions
pi0      = char(Z, 0)
H        = (X + Z)/sqrt(2)
CNOT     = ctrl(Z, [I, X])
phi_circ = CNOT*(H @ I)

# Initial global state
def initial_state(U):
    return (U @ phi_circ) << pi0 @ pi0 @ pi0

# Bell states and dual projectors
def Phi(a, b):
    init = proj(Z, a).e @ proj(Z, b).e
    return phi_circ.d >> init

bell_PVM     = [Phi(0,0)@I, Phi(0,1)@I, Phi(1,0)@I, Phi(1,1)@I]

# Measurement and correction
def corrected(U):
    bell_measure = stMeasure(bell_PVM, initial_state(U))
    measured, i  = bell_measure()
    a, b         = int(f"{i:02b}"[0]), int(f"{i:02b}"[1])
    return (I @ I @ (X**a * Z**b)) << measured

Note that on the second last line, we write \(i\) as a binary string and extract the bits. We can condense this further if we want to play code golf:

$alg = <X, Z | herm, unit, anti>

phi_circ = ctrl(Z,[I,X])*((X+Z)/sqrt(2) @ I)

def ψ(U): return (U @ phi_circ) << (@3) char(Z, 0)
def Φ(a, b): return phi_circ.d >> proj(Z,a).e @ proj(Z,b).e
def corrected(U):
    m, i  = stMeasure([Φ(a,b)@I for a in (0,1) for b in (0,1)], ψ(U))()
    return (I @ I @ (X**((i >> 1) & 1)) * Z**(i & 1))) << m

At seven lines, it's far less intelligible (in particular the bit-shifting at the end), and we've also introduced the prefix notation (@n) for repeated tensor powers. But it's remarkably compact for a complete implementation of teleportation: a magic trick with no sleight of hand!
